K-BLUM Legrabox C Pure 500 mm/70 kg, Tip-on, st. steel, internal, glass
Product range code
344988
Set
Images are for illustration only and may not correspond to reality. The parameters of the actual embodiment are included in the product name and description.
Description and parameters
Related product range (accessories) (1)
Alternatives
The set contains fittings for assembling one drawer, including front fittings. Must be supplemented with a front plate or glass or railing. The TIP-ON version should be supplemented with synchronization. Synchronization - pinions (227606) and shaft (227607). The length of the shaft is 1160 mm and without shortening it is suitable for the outer width of the body up to 1400 mm.
Parameters
| Parameter | Value |
|---|---|
| Attached front fittings | Inner |
| Colour | Stainless steel |
| Headroom of drawer (mm) | 193 |
| Length (mm) | 500 |
| Load capacity (kg) | 70 |
| Movement of extended drawer | Handleless |
| Sidewall height (mm) | 177 |
Composition of the set
| Title | Code | Quantity in set | Price excluding VAT | |
|---|---|---|---|---|
|
BLUM 753.5001T slide Legrabox 500mm/70kg Tip-on | 227429 | 1 pair | 45,0715 EUR |
|
BLUM 770C5002I sidewall Legrabox C 500mm stainless steel | 227516 | 1 pair | 74,4662 EUR |
|
BLUM ZB7C000S back fixings bracket Legrabox C nickel | 227564 | 1 pair | 5,5024 EUR |
|
BLUM ZI7.2CI0 front bracket Legrabox C stainless steel | 227577 | 1 pair | 36,3375 EUR |
| Title | Code | Availability |
Divisibility/ packaging |
Basic price per unit | |
|
Tips for a better price
Order the whole package and your price per pc (pcs) will be %price% |
11109 |
>
S
In stock
|
1,000 pcs / 1,000 pcs |
0,0082 EUR
/ pcs
0,0099 EUR incl. VAT
|
|
| Title | Code | Availability |
Divisibility/ packaging |
Basic price per unit | |
|
Set
Tips for a better price
Order the whole package and your price per pc (set) will be %price% |
344986 |
>
S
In stock
|
1 set / 1 set |
156,1022 EUR
/ set
188,8837 EUR incl. VAT
|
|
