K-HETTICH InnoTech Atira, internal, white, 520/70 50kg, PTO
Complete set of fittings for the InnoTech Atira drawer as described in the product name - including drawers and front fitting (dowel). For 144mm and 176mm height drawers, longitudinal relingues are also included. For internal drawers, the transverse front elements (front plate, front reling) must be added. Push To Open (PTO) slides with catchless opening integrated in the slides. For enclosures wider than 600mm it is necessary to add synchronisation bar 318279 (length 2000mm, shortening = internal width of enclosure - 66mm) and 2 pcs of adapter 318282. For narrower housings the use is recommended.
Parameters
| Parameter | Value |
|---|---|
| Attached front fittings | Inner |
| Colour | White |
| Headroom of drawer (mm) | 70 |
| Length (mm) | 520 |
| Load capacity (kg) | 50 |
| Movement of extended drawer | With damping |
Composition of the set
| Title | Code | Quantity in set | Price excluding VAT | |
|---|---|---|---|---|
|
HETTICH 9307142 Atira flexi complete set 520/70 white | 486167 | 1 set | 31,7308 EUR |
|
HETTICH 9196348 Atira inner drawer front attachment 70 white | 295276 | 1 set | 10,3766 EUR |
|
HETTICH 9143435 Quadro V6+ 520mm EB10.5 P2O L+P | 210394 | 1 set | 57,6359 EUR |
| Title | Code | Availability |
Divisibility/ packaging |
Basic price per unit | |
|
Tips for a better price
Order the whole package and your price per pc (pcs) will be %price% |
11109 |
>
S
In stock
|
1,000 pcs / 1,000 pcs |
0,0082 EUR
/ pcs
0,0099 EUR incl. VAT
|
|
| Title | Code | Availability |
Divisibility/ packaging |
Basic price per unit | |
|
Set
Tips for a better price
Order the whole package and your price per pc (set) will be %price% |
358028 |
>
O
On demand
|
1 set / 1 set |
99,7434 EUR
/ set
120,6895 EUR incl. VAT
|
|
