K-HETTICH WingLine S Push2M, 5 kg, 1800 mm, 4 hinges P, right+left, grey
Product range code
504623
Set
Images are for illustration only and may not correspond to reality. The parameters of the actual embodiment are included in the product name and description.
Description and parameters
Complete set of WingLine S Push to move fittings for medium heavy door up to 5 kg with opening on the right and left side, including the opening mechanism, top guide and folding door hinges, without bottom guide. The door opens with a short push, it must be pushed again when closing. For wing width 300 - 450 mm and up to a height of 500 mm, cabinet width max 1800 mm. Number of hinges between the doors - 4 pcs for pressing-in. Color grey. It is necessary to purchase the arrester and the recommended side hinges, see related assortment. Assembly instructions can be found on our website for the individual products of this set.
Parameters
| Parameter | Value |
|---|---|
| Colour | Gray |
| Fill (mm) | 16 - 22 |
| Load capacity (kg) | 5 |
| Maximum leaf width (mm) | 450 |
| Orientation | Right+Left |
| Type | WingLine S Push |
Composition of the set
| Title | Code | Quantity in set | Price excluding VAT | |
|---|---|---|---|---|
|
HETTICH 9278788 WingLine L folding curtains 2 pcs to press | 409246 | 2 set | 19,7425 EUR |
|
HETTICH 9283265 WingLine S shock absorber gray | 409309 | 2 pcs | 0,6344 EUR |
|
HETTICH 9279162 WingLine S upper guide profile 2400 mm anodized aluminum | 409315 | 1 pcs | 25,7862 EUR |
|
HETTICH 9266112 WingLine L/S Push2M mechanism for medium-duty doors gray P | 409270 | 1 set | 61,8547 EUR |
|
HETTICH 9265960 WingLine L/S Push2M mechanism for medium-duty doors gray L | 409267 | 1 set | 61,8547 EUR |
|
HETTICH 9283243 WingLine S Push to move silent gray right | 409306 | 1 set | 8,0097 EUR |
|
HETTICH 9283248 WingLine S Push to move silent gray left | 409303 | 1 set | 8,0097 EUR |
