K-HETTICH WingLine S Push2M, 5 kg, 900 mm, 3 hinges P, left, grey
Product range code
504600
Set
Images are for illustration only and may not correspond to reality. The parameters of the actual embodiment are included in the product name and description.
Description and parameters
Complete set of WingLine S Push to move fittings for medium heavy door up to 5 kg with opening on the left side, including the opening mechanism, top guide and folding door hinges, without bottom guide. The door opens with a short push, it must be pushed again when closing. For wing width 300 - 450 mm and up to a height of 1000 mm, cabinet width max 900 mm. Number of hinges between the doors - 3 pcs for pressing-in. Color grey. It is necessary to purchase the arrester and the recommended side hinges, see related assortment. Assembly instructions can be found on our website for the individual products of this set.
Parameters
| Parameter | Value |
|---|---|
| Colour | Gray |
| Fill (mm) | 16 - 22 |
| Load capacity (kg) | 5 |
| Maximum leaf width (mm) | 450 |
| Orientation | Left |
| Type | WingLine S Push |
Composition of the set
| Title | Code | Quantity in set | Price excluding VAT | |
|---|---|---|---|---|
|
HETTICH 9278787 WingLine L folding curtains 3 pcs to press | 409248 | 1 set | 33,164 EUR |
|
HETTICH 9279130 WingLine S upper guide profile 1200 mm anodized aluminum | 409312 | 1 pcs | 14,5226 EUR |
|
HETTICH 9283265 WingLine S shock absorber gray | 409309 | 1 pcs | 0,7104 EUR |
|
HETTICH 9265960 WingLine L/S Push2M mechanism for medium-duty doors gray L | 409267 | 1 set | 69,2721 EUR |
|
HETTICH 9283248 WingLine S Push to move silent gray left | 409303 | 1 set | 8,9702 EUR |
